  • Solid-State Electronic Drive Circuit
  • Quartz-Crystal for Accurate Timing
  • Quiet Operation – Permanently Lubricated
  • High-Impact, Tamper-proof Plastic Case
  • Sealed Against Moisture and Dirt
  • Indicates Operating Time in Hours and Tenths
  • No Battery Back Up Required
  • Made in the U.S.A.

The TM Series hourmeters record the operating time of vehicles or powered equipment. They are electromechanical and have a quartz base time counter that ensures accuracy (better than ±0.02% over the entire range). They can record up to 99,999.9 hours (9,999.9 for TM612/624) and include an automatic recycle to zero hours feature. The TM Series models have a shock-proof and tamper-proof, totally sealed case made of an engineered plastic. These small, lightweight time meters are rugged and durable. They are the answer to applications requiring a low DC power and reliable hourmeter. The TM612/624 model includes a three-hole mounting shock ring for extreme shock protection.

These hourmeters can be used on any engine where operating time needs to be recorded. All it requires is a DC power source (refer to Specifications).

Basic Models

6-Digits Hourmeters
Model           Bezel Type
TM4592        Bright Stainless Steel Bezel
TM4593        Black Stainless Steel Bezel\
TM4594        SAE Bright Stainless Steel Bezel
TM4595        SAE Stainless Steel Black Bezel

5-Digits Hourmeter with Shock Ring Mounting
TM612/624     3-Hole Mount, Black Bezel


Power Input: 12 to 24 VDC

Power Consumption: Less than 0.03 W @ 12 VDC; 0.4 W @ 24 VDC.

Accuracy: ± 0.02% over entire range.

Temperature Range: -40°F to 185°F (-40°C to +85°C).

Dial (Face Plate): White numerals (over black background).

Time Scale:

  • TM4592-95 models: 6-digits 99,999.9 hours;
  • TM612/624 models: 5-digits 9,999.9 hours.
  • Automatic recycle to zero.

Vibration Resistance: Withstands 10 to 75 Hz @ 1 to 8 G’s.

Case Material: Plastic.

Bezel: Stainless Steel.

Terminations: 1/4 in. (6 mm) male blade terminals.

TM4592/4595 Shipping Weight: 5 ozs. (140 g).

Shipping Dimensions: 3-1/8 x 3 x 3 in. (79 x 76 x 76 mm) approximately.

TM612/624 Shipping Weight: 8 ozs. (230 g).

TM612/624 Shipping Dimensions: 5 x 5 x 3-1/4 in. (127 x 127 x 83 mm) approx.



Typical Wiring
