The PowerView Analog Gages (PVA) are a series of intelligent gages designed to display easy-to-read information transmitted by the PowerView. The PVA gages communicate with the PowerView via a single RS485 twisted pair MODBUS RTU serial link. The gages can be daisy-chained using quick-connect harnesses with watertight connectors.

The major feature of the PVA gages is its balance between design and functionality. These modern gages offer a selection of lens and bezel styles and colors.

The PVA gages also include features such as a smooth stepper motor operation for the 270-degree sweep pointer, an environmentally sealed case with two Deutsch DT style connectors molded into the case and green LED backlighting.

They are available for standard 2-1/6-inch (52mm) and 3-3/8-inch (86mm) diameter mounting hole sizes. In addition, the polycarbonate/polyester alloy cases incorporate a D shape allowing panel cutouts that eliminate gage rotation during installation.

The PowerView Audible Alarm (PVAA) alerts operators to fault conditions via piezoelectric alarm and relay contacts. It also has a temporary silencer button that silences the audible tone for two minutes on warnings and 30 seconds on shutdown conditions. All PowerView gages can be powered by 12- or 24-VDC systems.

  • Power Supply Input: 12/24V (8-32VDC min/max voltage)
  • Power Supply Operating Current: (@ 14VDC) =
    • PVA20, PVA35: 28 mA minimum: 52 mA maximum
    • PVAA20: 19 ma minimum; 46 mA maximum
  • Backlight Maximum Current: 24 mA (Not valid for PVAA20)
  • Input: RS485 MODBUS RTU Data
  • Output: Analog readout
  • Operating Temperature: -40°F to 185°F (-40°C to 85°C)
  • Storage Temperature: -76°F to 185°F (-60°C to 85°C)
  • Dial: White text over black background
  • Indicating Pointer: Stepper motor Operation with 270° sweep
  • Gage Accuracy: Better than ± 1% of full scale
  • Environmentally Sealed Enclosure:
    • Sealing: IP68, ±5 psi (±34.4 kPa)
    • Case Materials: Polycarbonate/Polyester (PC+PBT)
    • Clamp Materials: Polyester (PBT)
    • Lens Material: Polycarbonate
    • Bezel Material: ABS
  • Maximum Panel Thickness: 3/8 inch (9.6mm)
  • Connectors: 6-pin Deutsch DT06 Series

The following items apply only to PVAA20

  • Sound Output Level: 90 dB @ 30cm
  • Relay Rated Load: 0.5A, 125VAC: 1A, 24VDC
  • Relay Maximum Switching Capacity: 62.5VA, 30W
  • External Audible Alarm Output: 28VDC, 30 mA maximum current sink
  • Temporary Silence Button: Charge transfer technology
